Equipment operation

(5) Remove the front support poles from the
wakeboard tower, and then place the 1
poles in the flap of the bimini top.

1

2

1 Bimini top
2 Lock pin

Installing the bimini top
1 Front support pole
To install the bimini top:
(6) Pull the front of the bimini top toward the When installing the bimini top, simply reverse
stern, wrap the bimini top around the the removal steps, and then make sure that
main pole, and then install the storage the lock pins are securely installed.
cover.

Trailering with the bimini top
The bimini top must be secured to the boat
when it is being trailered. When the boat is
trailered with a genuine Yamaha boat cover,
simply store the bimini top in the fully col-
lapsed position and install the storage cover.
If a boat cover is not used, wrap an elastic
cord around the top and secure the ends to
the tow pylon on the wakeboard tower to re-
strict movement.

Removing the bimini top
To remove the bimini top:
(1) Store the bimini top. See “Storing the bi-
mini top”.
(2) While supporting the bimini top, rotate
the lock pins securing the main pole to
the wakeboard tower, and then remove
the top.

127
