Equipment operation

(5) Push the snap button and extend each (7) While pulling the main pole down, push
rear support pole to the long position. the snap button and shorten each rear
support pole to either the middle position
for cruising or to the short position if you
1 are using the wakeboard tower. Be sure
2 the snap buttons click into place.
3
4 1
5
2

3
1 Rear support pole 4
2 Snap button
3 Short position
4 Middle position
5 Long position
1 Rear support pole
2 Short position
(6) Secure each rear support pole to the rear
3 Middle position
support pole mounting bracket using the 4 Snap button
lock pin.
NOTICE
1
z Do not exceed 72 km/h (45 mph) with the
bimini top in the up position.
2 3 z Be careful not to push the snap button
and extend the pole too far. Otherwise,
the lower section of the pole could fall
into the water.

1 Rear support pole
2 Lock pin
3 Rear support pole mounting bracket

125
