Equipment operation

(2) Rotate the lever to port (left).

5

2 3
4
1

1 Rear starboard seat
2 Starboard engine hood seat (3) Move the seat to the desired position,
3 Port engine hood seat and then release the lever.
4 Rear port seat
(4) Push the lever to its original position.
5 Handgrip
To swivel the seat:
(1) Extend the slide/swivel lock lever.
Driver’s seat
(2) Rotate the lever to starboard (right).
The driver’s seat can slide forward and rear-
ward, and the seat can swivel, and the back-
rest angle can be adjusted. In addition, the
seat bolster at the front of the seat can be
flipped up to change the seat style for a
raised seating position.
Make sure that the seat is securely locked in
place before getting underway.
To slide the seat:
(1) Extend the slide/swivel lock lever.

1
1 Slide/swivel lock lever

99
