Instrument operation

Warnings
If a malfunction or fault occurs, a warning buzzer will sound and a warning icon and warning
message will be displayed on the center display.
If the displayed warning message includes instructions, follow those instructions. If you have
any questions, consult a Yamaha Boat dealer.

NW
NW N N NE
NE
F
F FUEL DEPTHTHH
DEPTH
FUEL
O
FL
O
AT M
1 50 50 50 5 % % % FLOAT MODEDE 0 0 0 Ft F F Ft t t
Check Engine !
2 Consult YAMAHA dealer.
°F °F
OK
Water Tempp
W ater T em
STARTTART HOUSE
S
OUSE
H
.1
1 12.1 V V 12.00 V V
2
12.
1 Warning title
2 Message
Warning example
Warning title Message
Check Engine Consult YAMAHA Dealer.
Low Oil Pressure Consult YAMAHA Dealer.
Check Battery Low Voltage detected.
Consult YAMAHA Dealer.
GPS Communication Failure Consult YAMAHA Dealer.
Transducer Communication Failure Consult YAMAHA Dealer.
Engine Over Temperature Consult YAMAHA Dealer.
Low Fuel Fuel level is low. Please refuel soon.
Low Fuel Warning Fuel level is less than 10%.
Depth Warning Depth alarm limit reached.
