Instrument operation

 Push the “CRUISE/NO WAKE” (–) button
repeatedly until “No Wake” disappears.
 Push the remote control levers forward to
open the throttle.

Operating the boat in reverse with
more thrust (reverse RPM control)
Engine speed in reverse is limited to approx-
imately 4500 rpm. If more thrust is required
when the boat is traveling in reverse, use the
reverse RPM control. WARNING! Be pre-
pared to reduce throttle as soon as the
boat moves as desired. Otherwise, the
boat may become unstable, which could
result in loss of control and an accident.
To activate the reverse RPM control:
(1) Move the remote control levers back-
ward so that the throttle is opened in re-
verse and both engines are operating at
the same engine speed.
(2) Increase the engine speed to 4500 rpm,
and then push the “CRUISE/NO WAKE”
(+) button.
Once the reverse RPM control is activated,
pushing the “CRUISE/NO WAKE” (+) button
will increase the available engine speed by
approximately 500 rpm in 3 stages up to a
maximum of 6000 rpm, and pushing the
“CRUISE/NO WAKE” (–) button will decrease
the available engine speed. However, the ad-
justment is limited to these 3 increments.
To deactivate the reverse RPM control:
Operate the remote control levers to de-
crease the engine speed to less than 4500
rpm.

75
