Instrument operation

Language setting screen er use only, please consult your dealer if
The language for the multi-function display something was accidentally changed.
unit can be changed.
To drain the water in a ballast tank:
(1) Touch and hold the setting screen tab for
Set Language
5 seconds.
(2) Tap the “Ballast Times” button.
English Espanol

Francais
Diagnostics Menu
Port Engine Starboard Engine
Back PDM Diagnostics Software Information
BCU Ballast Times

To change the language, tap the desired lan-
guage. Load Software

Tuner Region setting screen
Set the region in which the multi-function dis- (3) Tap the “Flush-Out Ballasts” button.
play unit will be used.

Diagnostics Menu
Tuner Region
Ballast Times
North America South America
Flush-Out Ballasts
Japan Taiwan
Back
Back

(4) Tap the “OFF” button to change it to
To change the tuner region, tap the desired “ON” to start draining the water.
region.

Flush-out ballasts (252XE)
The flush-out ballasts can be used to drain
the water in the ballast tanks with the multi-
function display unit.
TIP:
The diagnostics menu is for dealership use.
All other functions on this screen are for deal-

92
