Instrument operation

Factory reset screen
This screen can be set to the factory settings.
Ballast Overdrain Initiated

Are you sure you would like to reset to Port Center Stbd
factory settings?
30 30 30
You cannot undo this action!
OFF ON OFF

Cancel Confirm
TIP:
To reset to the factory setting:  The flush-out time cannot be adjusted. The
(1) Tap “Confirm”. default setting is 30 seconds to avoid dam-
(2) When the confirmation message ap- aging a ballast pump when there is no wa-
pears, tap the “YES” button. ter remaining in a tank and/or to prevent
excessive battery drain.
Flush-out ballasts (252XE / 255XE /  If the flush-out time is not sufficient to re-
255XD) move all the water from a tank, continue
The flush-out ballasts can be used to drain the draining process until it is empty. Stop
the water in the ballast tanks with the multi- the process immediately once all the water
function display unit. has been removed from each tank.
If you have any questions, consult a
To drain the water in a ballast tank: Yamaha Boat Dealer.
(1) Tap the Drive Control Screen Tab.
(2) Tap Ballast Level. (5) When finished, tap “ON” to return to the
(3) Set the value of the tank you want to previous screen.
drain to 0.

Fill All Drain All
0 0 0

Back Activate

(4) Tap “ ”. “Ballast Overdrain Initiated” is
displayed, and draining starts.

102
